The VA-GW760 digital vacuum gauge, or wireless digital vacuum meter, obtains accurate measurements during the vacuum process of the compressor system, eliminating all impurities or moisture. VA-GW760 can also be used to evaluate system leakage and discern vacuum pump quality. It is made of abs plastic and metal, and a sensor whose functionality is to measure microns during the vacuum process. It has a range from 0 to 19 thousand microns. In addition, it is made to work in different environments, since it can operate from -178ºC to 60ºC. Its main functionalities include data logging, report generation and configuration of high and low pressure alarms from its screen or mobile app.
| VACUUM RANGE | 0-19,000 microns |
| APPLICATION | Refrigeración, aire acondicionado, industrial |
| MATERIAL | ABS and Metal |
| COLOR | Black / Blue |
| OVERPRESSURE | 27.5 bar |
| BATTERIES | Internal rechargeable lithium |
| INCLUDES | Cloth Case |
| MEASUREMENT UNIT | micrones, mTorr, in/hg, KPa, Torr, mbar, psi |
| MEASUREMENT TYPE | Vacío del sistema de compresor |
| DIFFERENTIAL | 10% +/- (100-1000 microns) |
| RESOLUTION | 1 microns (for 0-400 micras) |
| OPERATING TEMPERATURE | -4 a 140°F / -20 a 60°C |
| PRECISION | 10% +/- (100-1000 micrones) |
| DISPLAY | Digital |
